Kwikstage Ladder Access Transom Angle Iron
Kwikstage System Scaffolding Made by High Quality Q235 or Q345 Strengh Steel Angle Iron(Normal Angle Iron Size:40x40x4.0mm--Normal Tube Size:?48.3x3.25mm)-Kwikstage Scaffolding Transom
Kwikstage Ladder Access Transom
1.Normal Angle Iron Size:40x40×4.0mm–Normal Tube Size:?48.3x3.25mm
2.Available in Painted,Hot Dip Galvanized Surface or Customized
Transom component used for insertion into scaffold bay. Allows installation of a ladder opening within the scaffold deck.There are angle iron type and tube type.
|
Item No. |
Description |
Length |
Unit Weight |
|
|
RKAT 070 |
0.70M Ladder Access Transom |
0.70M |
5.30 KG |
11.68 LBS |
|
RKAT 120 |
1.20M Ladder Access Transom |
1.20 M |
7.50 KG |
16.53 LBS |
|
RKAT 180 |
1.80M Ladder Access Transom |
1.80 M |
13.20 KG |
29.10 LBS |
|
RKAT 240 |
2.40M Ladder Access Transom |
2.40 M |
16.50 KG |
36.38 LBS |
Note: Other Size Can be Customized
Descriptions:
Material:High Quality Q235 or 345 Strengh Steel
Tube:4Normal Angle Iron Size:40x40×4.0mm–Normal Tube Size:?48.3x3.25mm
Surface Treament:Galvanized ,Hot Dip Galvanized ,Painting ,Powder coated, others
Packing:Steel Pallets with Plastic Membrane
Brand:RRICOM;RSF
OEM:Available
Note:Our factory can do all kinds of specifications Kwikstage System Scaffold Products based on our customer’s drawings or samples
