Snap to Snap Diagonal Brace
Snap to Snap Diagonal Brace
1.Normal Tube Size:48.3x3.20mm
2.Available in Hot Dip Galvanized Surface or Customized
|
Item No. |
Description(Bay Size:WxH) |
Unit Weight |
|
|
RSDB-C1 |
5′x2.00M Snap to Snap Brace |
11.90 KG |
26.24 LBS |
|
RSDB-C2 |
7′x2.00M Snap to Snap Brace |
13.50 KG |
29.76 LBS |
|
RSDB-C3 |
8′x2.00M Snap to Snap Brace |
14.30 KG |
31.53 LBS |
|
RSDB-C4 |
9′x2.00M Snap to Snap Brace |
15.30 KG |
33.73 LBS |
|
RSDB-C5 |
10′x2.00M Snap to Snap Brace |
16.20 KG |
35.71 LBS |
|
RSDB-C3 |
98.5″x2.00M Snap to Snap Brace |
14.50 KG |
31.97 LBS |
|
RSDB-C4 |
70.9″x2.00M Snap to Snap Brace |
12.60 KG |
27.78LBS |
|
RSDB-C5 |
63″x2.00M Snap to Snap Brace |
12.10 KG |
26.68 LBS |
Note: Other Size Can be Customized .
Descriptions:
Material:High Quality Q235 or 345 Strengh Steel
Tube:48.3×3.25mm or other required
Surface Treament:Galvanized ,Hot Dip Galvanized ,Painting ,Powder coated, others
Packing:Steel Pallets with Plastic Membrane
Brand:RRICOM;RSF
OEM:Available
Note:Our factory can do all kinds of specifications Cuplock System Scaffold Products based on our customer’s drawings or samples
